PACKING DETAILS: WEIGHTS, VOLUMES

APPROX. PACKING, WEIGHT AND VOLUME SPECIFICATIONS

RAM  SIZE                  UNITS                                                      HEIGHT DIMENSION                  BASE DIMENSION                    WEIGHT                 VOLUME
No.3 Centimetres 43.5 38 x 33 27 kg 0.05m3
No.3 Inches 17 1/4″ 15″ x 13″ 27 kg 0.05m3
No.4 Centimetres 48.5 38 x 34 36 kg 0.062m3
No.4 Inches 19″ 15″ x 13 1/2″ 36 kg 0.062m3
No.5 Centimetres 65 46 x 35 57 kg 0.104m3
No.5 Inches 25.6″ 18.11″ x 13.77″ 57 kg 0.104m3
No.6 Centimetres 82 53 x 49.5 98 kg 0.215m3
No.6 Inches 32 1/4″ 21″ x 19 1/2″ 98 kg 0.215m3
No.7 Centimetres 93 63.5 x 54.5 169 kg 0.322m3
No.7 Inches 36 1/2″ 25″ x 21 1/2″ 169 kg 0.322m3
No.10 Centimetres 114.5 66 x 89 388 kg 0.672m3
No.10 Inches 45″ 26″ x 35″ 388 kg 0.672m3

NOTES:

  • Dimensions are very close however, minor variations may occur due to timber thickness variations.
  • Ram Sizes No.3 to No.7 inclusive are bolted to a sturdy timber base, fully surrounded by a sturdy timber frame and cover.
  • Ram Size No. 10 is bolted to a sturdy timber base with packing around the Impetus Valve. It is shipped with the Dome unprotected.
  • Designated weights include packing and timber packing.
  • All above details may be subject to alteration without further notice.
  • Other non standard timber crates may be used for Billabong Hydraulic Water Ram freight from time to time, pending stock availability of standard timber crates.
